OpenSSL Strategic Architecture

OpenSSL Management Committee (OMC)

January, 2019

Introduction

This document outlines the OpenSSL strategic architecture. It will take multiple releases, starting from 3.0.0, to move the architecture from the current “as-is” (1.1.1), to the future “to-be” architecture.

Numerous changes are anticipated in the to-be architecture. A migration path for handling the eventual transition will be provided. The OpenSSL 3.0.0 release will have minimal impact to the vast majority of existing applications, almost all well-behaved applications will just need to be recompiled.

The current functionality provided by the engine interface will be replaced over time via a provider interface. OpenSSL 3.0.0 will continue to support engines. The to-be architecture will not be fully realised until OpenSSL 4.0.0 at the earliest.

As-is architecture

Currently, OpenSSL is split into four principal components:

  1. libcrypto. This is the core library for providing implementations of numerous cryptographic primitives. In addition it provides a set of supporting services which are used by libssl and libcrypto, as well as implementations of protocols such as CMS and OCSP.

  2. Engine. The functionality of libcrypto can be extended through the Engine API.

    Typically engines are dynamically loadable modules that are registered with libcrypto and use the available hooks to provide cryptographic algorithm implementations. Usually these are alternative implementations of algorithms already provided by libcrypto (e.g. to enable hardware acceleration of the algorithm), but they may also include algorithms not implemented in default OpenSSL (e.g. the GOST engine implements the GOST algorithm family). Some engines are provided as part of the OpenSSL distribution, and some are provided by external third parties (again, GOST).

  3. libssl. This library depends on libcrypto and implements the TLS and DTLS protocols.

  4. Applications. The applications are a set of command line tools that use the underlying libssl and libcrypto components to provide a set of cryptographic and other features such as:

    1. Key and parameter generation and inspection
    2. Certificate generation and inspection
    3. SSL/TLS test tools
    4. ASN.1 inspection
    5. Etc

Currently, OpenSSL has the following characteristics:

  1. EVP. The EVP (envelope) API level provides the high-level abstract interface to cryptographic functionality separate from the concrete implementation binding. Direct use of concrete cryptographic algorithm implementations via interfaces other than the EVP layer is discouraged. The EVP layer also provides composite operations, such as signing and verifying. Certain composite operations are also provided as an EVP-level operation (such as HMAC-SHA256). EVP also allow use of cryptographic algorithms in an algorithm-agnostic manner (e.g. EVP_DigestSign works for both RSA and ECDSA algorithms).

  2. FIPS140 is not supported. FIPS140 it is only available in OpenSSL-1.0.2 which predates the as-is architecture and is not API or ABI compatible.

Conceptual Component View

The existing architecture is a simple 4 level layering with the crypto layer at the bottom. The TLS layer depends on the crypto layer, and the applications depend on both the TLS and crypto layers.

Note: the existence of a component in the diagram does not indicate that the component is a public API or intended for end-user direct access or usage.

Packaging View

The components described above are packaged into libraries (libcrypto and libssl) and associated engine interfaces as well as an “openssl” command line executable for running the various applications. This is illustrated in the diagram below.

To-be Architecture

The to-be architecture has the following features:

  • Core Services form the building blocks usable by applications and providers. (e.g. BIO, X509, SECMEM, ASN1, etc).

  • Providers implement cryptographic algorithms and supporting services. A provider has implementations of one or more of the following:

    • The cryptographic primitives for an algorithm, e.g. how to encrypt/decrypt/sign/hash etc.
    • Serialisation for an algorithm, e.g. how to convert a private key into a PEM file. Serialisation could be to or from formats that are not currently supported.
    • Store loader back ends. OpenSSL currently has a store loader that reads keys, parameters and other items from files. Providers could have a loader to load from another location (e.g. LDAP directory).

    A Provider may be entirely self-contained or it may use services that are provided by different providers or the Core Services. For example, an application may use the cryptographic primitives for an algorithm implemented by a hardware accelerated provider, but use the serialisation services of a different provider in order to export keys into PKCS#12 format.

    A default provider (which contains the core of the current OpenSSL cryptographic algorithm implementations) will be “built-in” but other providers will be able to be dynamically loadable at runtime.

    Legacy provider module(s) will provide cryptographic implementations for older algorithms (e.g., DES, MDC2, MD2, Blowfish, CAST). The OMC will publish a policy for how and when algorithms are transitioned from the default provider to the legacy provider.

    A FIPS provider that embodies the OpenSSL FIPS Cryptographic Module will be able to be dynamically loaded at runtime.

  • The Core enables access to the services offered by providers to applications (and other providers). Providers make methods available to the Core. The Core is the mechanism via which concrete implementations of where things such as algorithms are located.

    The Core will implement a property based look-up feature for finding algorithms, e.g. it might allow you find an algorithm where “fips=true”, or “keysize=128, constant_time=true”. The details of this will be determined in later design documents.

  • Protocol implementations. E.g. TLS, DTLS.

The to-be architecture has the following characteristics:

  • The EVP layer becomes a thin wrapper for services implemented in the providers. Most calls are passed straight through with little/no pre- or post-processing.

  • New EVP APIs will be provided to find the implementation of an algorithm in the Core to be used for any given EVP call.

  • Information will be passed between the core library and the providers in an implementation agnostic way.

  • Legacy APIs (e.g. low level cryptographic APIs that do not go via the EVP layer) will be deprecated. Note that there are legacy APIs to non legacy algorithms (e.g. AES is a non-legacy algorithm but AES_encrypt is a legacy API).

  • The OpenSSL FIPS Cryptographic Module will be implemented as a dynamically loaded provider. It will be self-contained (i.e. can only depend on system runtime libraries and services provided by the Core).

  • Other interfaces may also be transitioned to use the Core over time (for example OSSL_STORE might be considered for this).

  • Engine usage will evolve to providers. "Bye-bye-Engines, Hello-Providers".

Conceptual Component View

An overview of the conceptual components in the OpenSSL to-be architecture is as shown in the (pink nirvana) diagram below.

Note: the existence of a component in the diagram does not indicate that the component is a public API or intended for end-user direct access or usage.

The components shown here are as follows:

  • Applications: Command line applications, e.g. ca, ciphers, cms, dgst etc

  • Protocols: Provides capabilities for communicating between endpoints according to standard protocols

    • TLS Protocols: An implementation of all supported TLS/DTLS protocols and supporting infrastructure such as:
      • SSL BIO: A BIO for communication using TLS
      • Statem: The TLS state machine
      • Record: The TLS record layer
    • Other Protocols
      • CMS: An implementation of the Cryptographic Message Syntax standard
      • OCSP: An implementation of Online Certificate Status Protocol
      • TS: An implementation of the Timestamp Protocol
    • Supporting Services: Components specifically designed to support the implementation of protocol code
      • Packet: Internal component for reading protocol messages
      • Wpacket: Internal component for writing protocol messages

  • Core: This is a fundamental component that connects requests for a service (such as encryption) to a provider of that service. It implements the ability for providers to register their services along with the properties of those services. It also provides the ability to locate a service given a set of properties that the service must fulfil. For example, properties of an encryption service might include “aead”, “aes-gcm”, “fips”, “security-bits=128”, etc.

  • Default Provider: Implements a set of default services that are registered with the Core.

    • Supporting Services
      • Low Level Implementations: This is the set of components that actually implement the cryptographic primitives.

  • FIPS Provider: Implements a set of services that are FIPS validated and made available to the Core. This includes the following supporting services:

    • POST: Power On Self Test
    • KAT: Known Answer Tests
    • Integrity Check
    • Low Level Implementations: This is the set of components that actually implement the cryptographic primitives (to meet the FIPS-mandated self-contained requirement).

  • Legacy Provider: Provides implementations of older algorithms that will be exposed via EVP-level APIs.

  • Third-Party Provider: Not part of the OpenSSL distribution. Third Parties may implement their own providers.

  • Common Services: these form the building blocks usable by applications and providers. (e.g. BIO, X509, SECMEM, ASN1, etc).

  • Legacy APIs. The “low-level” APIs. The “legacy” here refers to the API, not the algorithm itself. For example, AES is not a legacy algorithm but it has a legacy API (e.g. AES_encrypt).

Packaging View

The various components described in the conceptual component view above are physically packaged into:

  • Executable application(s) for use by users

  • Libraries for use by application(s)

  • Dynamically loadable module(s) for use by the Core.

The physical packages shown here are:

  • Openssl executable. The command line application.

  • Libssl. This contains everything directly related to TLS and DTLS. Its contents will be largely the same as libssl in the as-is architecture. Note that some supporting services will be moved to libcrypto.

  • Libcrypto. This library contains the following components:

    • Implementations of the core services such as: X509, ASN1, EVP, OSSL_STORE etc
    • The Core
    • Protocols not related to TLS or DTLS
    • Protocol supporting services (e.g. Packet and Wpacket)
    • The default provider containing implementations of all the default algorithms

  • Libcrypto-legacy. Provides the legacy “low-level” APIs. Implementations of the algorithms for these APIS may come from any provider.

  • FIPS module. This contains the FIPS Provider that implements a set of services that are FIPS validated and are registered with the Core.

  • Legacy module. This contains the legacy provider.
